Lithium Ion solcellebatteri 51.2v 100ah 200ah 300ah

2024-08-27 11:02

Produkt beskrivelse

Nominel spænding	51.2V	51.2V	51.2V
Nominel kapacitet	100Ah	230Ah	304AH
Energi	5120Wh	11776Wh	15360wh
Series or Parallel Connection	16S1P	16S1P	16S1P
Maksimal opladningsstrøm	100A	200A	200A
Charge Current (-20 to - 10 ºC)	≤0.05C	≤0.05C	≤0.05C
Anbefalet ladespænding	56V-57.6V	56V-57.6V	56V-57.6V
BMS ladespændingsafbrydelse	57.6V (3.75±0.025vpc)	57.6V (3.75±0.025vpc)	57.6V (3.75±0.025vpc)
Tilslut spænding igen	54.6V (3.34 ±0.05vpc)	54.6V (3.34 ±0.05vpc)	54.6V (3.34 ±0.05vpC)
Dimensions (L x W x H)	440*435*222mm (17.3x17.1x8.74”)	480*248*618mm	475*255*770mm
Vægt	70KG with wooden packing	:116KG with wooden packing	138KG with wooden packing
Kommunikationsgrænseflade	RS485 (Optional)	RS485 (Optional)	RS485/CAN (Optional)
Etui materiale	Metal	Metal	Metal
Enclosure Protection	IP54	IP54	IP54
Maksimal kontinuerlig afgangsstrøm	100A	200A	200A
BMS-decharge aktuelle afskæring	105A	230A	230A
Tilslut spænding igen	45V	45V	45V
Udledningstemperatur	-20 to 60ºC (-4 to 140 ºF)	-20 to 60ºC (-4 to 140 ºF)	-20 to 60ºC (-4 to 140 ºF)
Opladningstemperatur	0 to 45ºC (32 to 113 ºF)	0 to 45ºC (32 to 113 ºF)	0 to 45ºC (32 to 113 ºF)

* Please Click Here:We Provide OEM /ODM Service !
* Quick Delivery From China.
Vi er forpligtet til at lave de sikreste lithiumjernfosfatbatterier.
Alle vores batterier har gennemgået strenge tests og er certificeret sikre til brug i applikationer rundt om i verden.
Alle lithium-batterier i vores salg overholder CE, UN38.3, MSDS og andre transportregler, hurtig levering fra stedet!
Hvis du har brug for produktrelateret certifikat, bedes du kontakte os for at sende til dig!
* For additional benefits For resellers

we provide super price for you and policy, We offer one-stop solar energy storage solutions,please contact us directly and we will tell you more. Most importantly, we can provide you with professional solutions tailored to your local market.



Products Feature

1.Excellent safety performance: Safest lithium iron phosphate battery, CE BIS, MSDS, UN38.3 approved, with built-in BMS.

2.Long cycle life and deep cycle: Performs more than 6000 cycles, 6-8 times longer than lead acid battery.

3.No memory effect, highly efficient and high energy density.

4.Compact size and light weight: 1/2 size & weight of lead acid battery

5.Excellent high temperature performance

6.Low self-discharge rate: < 3% per month

7.High IP standard: IP65 Waterproof.



Ansøgning

Vores fabrik



Forsendelse og pakning

Ofte stillede spørgsmål

Q1. Do you have MOQ (Minimum Order Quantity) limit?
A: No, ALL IN ONE do not have MOQ limit, 1pc sample order or small quantity is available.

Q2. Hvad med ledtiden?
A: Standard product lead time: Samples: 3-5 days, Bulk order: 3-4 weeks.
Customized product lead time: 3-4 weeks both for sample or bulk order.

Q3. How do you ship the goods? How about the Shipping time?
A: By air door to door (6-12 days): FEDEX, UPS or DHL, suitable for urgent small order.
By sea door to door (25-50 days): suitable for bulk order.
By sea to delivery port (20-35 days): Suitable for bulk order.
By Air to airport (3-5 days): Suitable for urgent heavy package.

Q4. How to proceed with an order?
A: Firstly, providing your requirements or applications, then we will provide battery solution and quote accordingly.
Secondly, confirming the order and do the deposit for it, then we will arrange the production.

Q5. Is it available to print my logo on the product?
A: Yes. For OEM Demand please send us your logo and we will make a label for the product. For product with metal/aluminum case, logo silk-print on the case is available.
